Blister Machine

Our advanced blister-packaging range provides cutting-edge solutions to meet diverse pharmaceutical packaging needs. Our offerings encompass high-performance machines, guaranteeing adaptability for various packaging materials such as thermoforming films and cold-form foils. Meanwhile, precision-driven machines equipped with the latest servo technology ensure robust forming and sealing capabilities, delivering enhanced speed and accuracy. Additionally, we offer a secure containment option that prioritizes operator safety, particularly for highly potent pharmaceutical ingredients. Moreover, our compact and versatile machines excel in short-run and small-batch blister-pack production, accommodating various configurations and materials.

Technical specification
Forming cycle
Thermoforming
Up to 50 cycles/min
Cold-forming
Up to 45 cycles/min
Forming depth
Thermoforming
Up to 12 mm
Cold-forming
Up to 9 mm
Maximum forming area
240 mm × 180 mm
Forming materials
PVC, PVC/PVdC, Aclar, Triplex (PVC/PE/PVdC), cold-form foil (Alu)
Lidding materials
Push-through foil, child-resistant foil, peelable (paper)
Technical specification
Output
Up to 4.5 m/min (Thermoforming)
Forming depth
Up to 28 mm (Thermoforming)
Maximum blister size
200 mm × 100 mm
Forming materials
PVC, PVC/PVdC, Triplex (PVC/PE/PVdC)
Lidding materials
Push-through foil, child-resistant foil, peelable (paper)

latest marvel in blister packaging technology, champions speed, embodying our commitment to exceed your high-output requirements.
